EVUP DC 400kW Smart Charger

Name: EVUP DC 400kW Smart Charger
Brand: EV Ultra Plus
Price: 999999.00 AUD
Availability: InStock

The EVUP DC 400kW Smart Charger is engineered to deliver ultra-high power for the fastest EV charging experience. With a rugged and durable casing and a vibrant color LCD display, it combines functionality with user-friendly operation, making it a standout choice for high-demand applications.

Designed for locations that require rapid and reliable charging, such as highways, commercial fleets, and heavy-duty transport hubs, the EVUP DC 400kW Smart Charger is the ultimate solution for high-performance EVs.

Product variants

Key Features

Available in 400kW

4G Data Module

RFID Card Reader

Integrated Smart Chip – OCCP 1.6

Color LCD Display

Waterproof & Dustproof (IP56)

Short Circuit Protection

Overcurrent Protection

Overheat Protection

Surge Protection

5M charging cable

Technical Specifications

DC Output Connection
Charging mode: CCS2 or CHAdeMO
Output power: Rated power DC 400kW
Output voltage: 200V ~ 1000V
Max output current: 350A
Number of outputs: 2*CCS2 or CHAdeMO
Peak efficiency >95%
AC Input Connection
Earthing system: 3P, N, PE
Input voltage/current: 3-phase 400V AC±15%, 620A
Input frequency: 45-65Hz
Power factor ≥0.99
Harmonic distortion (THDI) <5%
General Characteristics
IP and IK rating: IP56, IK08
Operating altitude <2000M
Operating temperature range: -30°C ~ +50°C
Storage temperature range: -40°C ~ +80°C
Mounting: Ground Mount
Dimensions: H:1765mm W:850mm D:780mm
Cable length: 5.0m Standard
User Interface
Status indication: LED / LCD / APP
User interface: Charge APP
Connectivity: 4G, LAN
Communication protocols: OCPP 1.6J (Can be upgraded to OCPP 2.0.1 later)
User authentification: APP, RFID Card, Credit Card (Optional)
Software Update: OTA updates via web portal
Certification and Standards
Safety and compliance: IEC 61851; IEC 62196; IOS 15118; IEC 61000-4-5
EMC compliance: EN55011; EN55022
Warranty: 24 months, warranty extension possible
Safety Protection
Multiple Protection: Over / Under voltage protection, Overload protection, Short Circuit Protection, Over / Under temperature protection, Grounding Protection, Surge Protection.
